Dell PowerEdge R770 2x Xeon 6507P 64GB RAM 480GB SSD 2x 1100W 2U Rack Server
Important Notice: This product has multiple configuration options. Product specifications may vary. Please chat with one of our friendly sales consultants before you purchase. While we do our best to ensure accuracy, sometimes there might be slight differences between our listings and the actual product specs. Thanks for your consideration.
Technical Specifications
| Specification | Details |
|---|---|
| Product | Dell PowerEdge R770 |
| Product Type | Rack Server |
| Form Factor | 2U |
| Processor Family | Intel Xeon 6 Performance |
| Processor Model | 6507P |
| Processor Frequency | 3.5 GHz / Up to 4.3 GHz (48 MB Cache, 8 Cores, 16 Threads per Processor) |
| Processors Installed | 2 |
| Maximum Processor Support | 2 |
| Internal Memory | 64 GB 6400 MHz (2 x 32 GB, Dual Rank) |
| Internal Memory Type | ECC DDR5 RDIMM |
| Memory Slots | 32 DIMM Slots |
| Max Memory | 8 TB |
| Total Storage Capacity | 480 GB |
| Storage Media | SSD |
| Installed Storage | 1 x 480 GB SATA Read Intensive 6Gbps 512e 2.5-inch Hot-Plug SSD, 1 DWPD |
| Drive Bays | Up to 8 x 2.5-inch SAS4/SATA Hot-Plug Drives |
| Storage Controller | Dell PERC H965i Controller, Front, DC-MHS |
| RAID Support | No RAID configured; hardware RAID supported through PERC H965i |
| Boot Mode | UEFI BIOS Boot Mode with GPT Partition |
| Expansion Slots | Riser Configuration 6: 4 x PCIe Gen5 x16 Full-Height Half-Length Slots, 1 x Gen5 x8/x16 OCP Slot and 1 x Gen5 x16 Second OCP Slot |
| Network Controller | Intel Ethernet E610-XAT2 Dual-Port 10GbE BASE-T OCP 3.0 Adapter |
| Network Connectivity | 2 x 10GbE BASE-T Ports, plus Dedicated BMC Management Port |
| Embedded Management | iDRAC10 Enterprise, Dell Connectivity Client and Dell Connectivity Module |
| Security Chip | TPM 2.0 Support |
| Security Features | Secured Component Verification, Secure Enterprise Key Manager 3.0, Secure Boot, Silicon Root of Trust and Cryptographically Signed Firmware |
| Operating System Installed | Not included (Optional) |
| Cooling | PowerEdge 2U High Performance Gold Fan Configuration |
| Power Supply | Dual (1+1) 1100 W Hot-Plug Redundant Titanium Power Supplies, 100–240 V AC |
| Bezel | PowerEdge 2U Standard Bezel Included |
| Rails | Not Included |
| Base Warranty | 3-years Basic Next Business Day |
| Included Upgrade | 3-years ProSupport and Next Business Day Onsite Service |
| Front Ports | 1 x USB 2.0 Type-C Port (Host/BMC Direct) 1 x USB 2.0 Type-A Port (Optional) 1 x Mini DisplayPort (Optional) 1 x DB9 Serial Port and Dedicated BMC Ethernet Port with Front I/O Configuration |
| Rear Ports | 1 x Dedicated BMC Ethernet Port 2 x USB 3.1 Type-A Ports 1 x VGA Port 2 x 10GbE BASE-T Network Ports |
| Internal Ports | 1 x USB 3.1 Type-A Port |
-
Specifications and Images may vary depending upon region / model.
Key Features
- 2U dual-socket rack server designed for high-performance enterprise workloads
- 2 x Intel Xeon 6 Performance 6507P processors
- 16 total processor cores and 32 threads
- 64 GB 6400 MHz ECC DDR5 RDIMM memory
- 480 GB enterprise SATA read-intensive hot-plug SSD
- 8 x 2.5-inch SAS4/SATA hot-plug drive chassis
- Dell PERC H965i front-mounted hardware RAID controller
- Intel E610-XAT2 dual-port 10GbE BASE-T OCP 3.0 network adapter
- iDRAC10 Enterprise for secure remote administration
- Dual 1100 W hot-plug redundant Titanium power supplies
- PowerEdge 2U standard bezel included
- 3-years ProSupport and Next Business Day Onsite Service
Features
High-Performance Dual-Socket Compute for Modern Data Centres
The Dell PowerEdge R770 is a powerful 2U, two-socket rack server designed for demanding virtualisation, database, analytics and mixed enterprise workloads. This Smart Selection configuration includes two Intel Xeon 6 Performance 6507P processors, 64 GB of ECC DDR5 registered memory and a 480 GB enterprise SATA solid-state drive.
With a flexible 8-bay 2.5-inch SAS4/SATA chassis, Dell PERC H965i hardware RAID controller, dual-port 10GbE OCP networking, iDRAC10 Enterprise remote management and redundant 1100 W Titanium power supplies, the PowerEdge R770 provides a secure and scalable foundation for modern infrastructure deployments.
Dual Intel Xeon 6 Processing
Two Intel Xeon 6 Performance 6507P processors provide a combined 16 cores and 32 threads. Each processor operates at a 3.5 GHz base frequency, reaches up to 4.3 GHz with Intel Turbo Boost Technology and includes 48 MB cache. The dual-processor configuration is well suited to consolidated applications, virtual machines and performance-sensitive business workloads.
Enterprise Memory and Storage
The system includes 64 GB of 6400 MHz ECC DDR5 registered memory configured as two 32 GB dual-rank RDIMMs. A 480 GB 6Gbps SATA read-intensive SSD provides reliable hot-plug storage, while the 8-bay 2.5-inch chassis and Dell PERC H965i controller support future SAS4 or SATA storage expansion.
Secure Remote Management
iDRAC10 Enterprise provides secure out-of-band monitoring, deployment and lifecycle management. The configuration also includes Secured Component Verification, Secure Enterprise Key Manager licensing, Dell Connectivity Client and Dell Connectivity Module support.
High-Speed Network Connectivity
An Intel Ethernet E610-XAT2 dual-port 10GbE BASE-T OCP 3.0 adapter provides high-bandwidth network connectivity for virtualisation, application traffic and storage networking. A separate dedicated BMC Ethernet connection supports remote management through iDRAC.
