Technical Specification

• CDP2HDUACP
• CDP2HDUACPW
• PEXUSB321C

Provide twice the data transfer speed of any other cable type, enable full 4K 60Hz video, and power your devices with a single cable.

Features

• Compatible with Thunderbolt, USB, and DisplayPort devices
• Supports 20Gbps data throughput
• Thunderbolt Certified
• Full 4K 60Hz video
• Single-cable docking while powering your laptop at the same time
• Daisy chain up to 6 devices

Faster data transfers with full 4K video

This cable supports data transfer rates of 20Gbps when connected to a Thunderbolt 3 device, so you can transfer photo and video files at twice the speed of a USB 3.1 Gen 2 (10Gbps) cable. For example, you can transfer a 4K movie in less than a minute. When connected to a USB 3.1 device, the cable supports data transfer rates of 10Gbps. The cable supports full 4K 60Hz video and DisplayPort 1.2, and is compatible with existing DisplayPort displays. It's perfect for connecting your docking station or laptop to a monitor with astonishing resolution, contrast, and color depth for amazing detail.

Versatile power delivery

This Thunderbolt 3 cable delivers up to 60W of power for charging a laptop or powering a display, and 15W for bus-powered devices such as a hard drive enclosure.

Thunderbolt networking

The cable gives you an easy way to bridge multiple Thunderbolt 3 enabled laptops for peer-to-peer 10GbE networking. It’s perfect for setting up small workgroups and sharing peripherals such as printers and storage. You can also connect two Thunderbolt 3 laptops together for PC migrations.

Applications

• Connect to any Thunderbolt display or data device
• Connect your Thunderbolt 3 laptop to a docking station, and power your laptop at the same time, with the same cable
• Set up peer-to-peer networking for multiple Thunderbolt 3 laptops
• Connect, charge, and sync your USB 3.1 devices (for example, mobile devices, portable hard drives, and docking stations) with a USB 3.1 capable computer
